The SIPROTEC 4 IO-Box 6MD61 enables
in a simple, easy way to enhance the number of binary inputs and outputs in the
switchgear. It can be used directly in the
bay together with other SIPROTEC4 units
and also together with SICAM PAS to serve
as a central process connection.
The IO-Box is based on the SIPROTEC
6MD63 and 6MD66 series, so it can be easily integrated in systems with other
SIPROTEC 4 units.
The IO-Box supports a wide range of demand for additional binary inputs ( BI) and
binary outputs ( BO) , starting from
20 BI+ 10 BO and going up to 80 BI+ 53 BO.
All important standard communication
protocols are supported. With
IEC 61850-GOOSE communication, a direct information interchange with other
SIPROTEC units is possible. For simplification and cost reduction, the IO-Box is
available only without automation ( CFC) ,
without keypad and without display
