Tipe RG-8
Impedance 50 Ohm

Conductor : Solid Bare Copper 2.74 + - 0.025mm
Dielectric : Foamed PE ( good adhesion to conductor ) 7.25 + - 0.13mm
Foil Shield : AL/ PET/ AL-Tape bonded to dielectric
Braid Shield : Solid tinned copperbraid , Coverage > 88% , 8.1mm
Jacket: Black PE- Material , ERICSSON TZC 500 32"

Capacitance : 78 pF/ m
Impedance : 50 Ohm
Velocity Factor : 87%
DC Resistance 3, 0/ 5, 9 Ohm/ Km
Frequency range : DC-4Ghz
Rated Voltage 600V AC
Breakdown Voltage 2600 V DC
Tesile Strenght = > 1500N
